Smooth round rubber belts / High tensile polyurethane cord 90A

চীন Wuxi Jiunai Polyurethane Products Co., Ltd সার্টিফিকেশন
চীন Wuxi Jiunai Polyurethane Products Co., Ltd সার্টিফিকেশন
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

তোমার দর্শন লগ করা অনলাইন চ্যাট এখন

Smooth round rubber belts / High tensile polyurethane cord 90A

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt

বড় ইমেজ :  Smooth round rubber belts / High tensile polyurethane cord 90A

পণ্যের বিবরণ:
Place of Origin: Wu xi city of China
পরিচিতিমুলক নাম: jiuna
সাক্ষ্যদান: ROHS
Model Number: Diameter2mm-20mm
প্রদান:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: L/C, T/T, L/C, Western Union, MoneyGram
Supply Ability: 100,000,00 as per month
বিস্তারিত পণ্যের বর্ণনা
Color: orange color hardness: 90A
longth: 400 m/roll Usage: Transmission Chain
type: PU rough round belt surface: smooth
material: PU
লক্ষণীয় করা:

pu extruded বেল্ট

,

সবুজ বৃত্তাকার বেল্ট

,

90A PU রুক্ষ বৃত্তাকার বেল্ট

Smooth round rubber belts / High tensile polyurethane cord 90A



Smooth Surface Urethane Round Belting Rohs Approved , Low Compression

Widely used in textiy

  printing and packing machine,food & beverage processing, wood processing  ,  paper processing electronic post service tobacco transmission line
 Wall floor tile conveying industrial line

Ceramic industry line or polishing line

We supply different kinds of PU V-belt, Round belt, Surper grip belt & Pentagon

Color: Orange, Red, Dark Green, Ivory, Natural  .

  • Shore Hardness:  Round belt - 87°A ± 2 .
  • Rough surface: Normal Rough / More Rough  .
  • Steel, Glass & Aramid Reinforcement on request.
  • Easily jointed with BCTech's Welding Kits
  • Features:
  • High tensile and tear strength
  • High abrasion resistance
  • Resistant to oil, grease, dust, moisture & most chemicals
  • Temperature Range: -35 ~ 85 Degrees
  • The types of TPU V-Belt:

Glossy surface round belt, rough surface round belt, v-belt, pentaone belt, hexagonal belt,

heptagonal belt, supper-grip belt, T belt, perallel belt.

Applications:
Mainly used in transmission and distribution products for the textile, clothing, food, packaging, printing, machinery, electronic, glass, chemicals, automobiles, beverages, furniture, toys, paper and other industries; Especially in the ceramic industry, widely used in the glazing Lines, transmission lines, polishing line etc.
Normal specifications including Z, M, A, B, C, D and the Pentangular Belt including A, B, C type, pentagonal belt normally used in the production line's corner.



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile   rate

Hardness

Length of rolled

DIA(mm)

 In

mm

    %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30



Smooth round rubber belts / High tensile polyurethane cord 90A 0

Smooth round rubber belts / High tensile polyurethane cord 90A 1

Service commitment:

“ Quality for keeping going ,Credit to win the world”
